Image Spot™

Brilliant Imaging.

Using a mere 45W of power, the Image Spot LED projector packs an amazing amount of light output from a versatile and compact design. The cool white LEDs and crystal clear optics ensure bright imaging in virtually any environment, and enable vivid gobo projection up to 40 feet (12m) away! Image Spot can also be used to create spot illumination for artwork in museums, accent lighting in hospitality venues or highlight products inside retail displays.

Image Spot is available in both IP40 and IP65 models, allowing it to be used indoors or outdoors. Please note that Image Spot does not ship with a lens. Choose from the available narrow, medium and wide lens accessories when ordering to achieve the imaging or beam spread your project requires.

Accepts Image Spot Gobos And Permacolor Dichroic Glass Filters

The Image Spot is ready to accept steel, Effects Glass, B&W & color glass gobos, or even our Cool Ink HD plastic gobos for short-term events or promotions. Choose any Rosco pattern – from the world’s largest library of standard gobo patterns – or, project a custom gobo with a specific image, logo or message. The Image Spot gobo cassette also accepts Rosco Permacolor dichroic glass filters for long term color correction or enhancement.

Crystal Clear Optics

Image Spot's engineered optics produce a light beam with the highest uniformity and resolution, which enables the fixture to project even illumination or a crisp gobo image at distances up to 40 feet (12m).

Designed For Use Indoors Or Outdoors

Available in two different variants – an IP40 model for indoor use and an IP65 model for outdoor use – the Image Spot offers the versatility to create spot-lighting or project gobos everywhere those effects may be required.

Integrated Filter Chamber

Many spot illumination applications require the beam to be diffused. The Image Spot offers diffusion integration with its easy-to-access filter chamber at the front of the lens tube. Use this chamber to add diffusion filters from the optional Image Spot OPTI-FLECS Filter Pack accessory, which comes with three diffusion materials that spread and shape the fixture’s beam. A retaining ring holds the filters securely in place.

Manual or DMX Controls

Control the output of the Image Spot using its on-board dimming controls or by connecting the Image Spot to a DMX control device for remote intensity control. The IP40 model connects to DMX via standard RJ45/Cat5 cable, while the IP65 unit connects via an optional, exterior-rated Cat5 cable.

Input Voltage: 100-240VAC

Power Consumption: 45 Watts at maximum output

Output: 3000 lumens

LED Color Temperature: 5500K

Lumen Maintenance: 50,000 hours at 45°C (LM-79-08)

Power Connection: 6.5 ft (2m) insulated cable, unterminated (connector not included)




RJ45 Connector (IP40)

2m Cat5e Cable/Gland (IP65)


DMX Addressing:

Rosco Programming Software

USB to RJ45 Programming Cable (IP40)

USB to RS485 Programming Cable (IP65)


Operating Temp.: 14° to 104° F (-10° to 40° C)

Humidity: 0 - 95% non-condensing

Dimensions: 7.8in x 4.8in x 3.2in (198mm x 121mm x 81mm) (excluding yoke)

Weight: 5.5 lbs (2.5 kg)

Housing: Anodized Aluminum Extrusion



ETL / UL Standards #62368-1 and #60950-22

cETL / CSA C22.2 #62368-1 and #6095-22


IP40 Rated (indoor use) or IP65 Rated (outdoor use)




Gobos & Permacolor Filters:

For optimum image quality and performance, use Rosco Image Spot gobos and Permacolor Filters, which feature custom bezels that fit securely inside the Image Spot gobo cassette.


Standard Gobos

XXXXX-SPOT                     Image Spot Standard Gobo, XXXXX = The five digit standard gobo number

Custom Gobos

2507210ISPOT                    Image Spot Custom Steel Gobo

260CUSBWOSPO              Image Spot Custom B&W Glass Gobo

260CUS1COSPO               Image Spot Custom One-Color Glass Gobo

260CUS2COSPO               Image Spot Custom Two-Color Glass Gobo

260CUSMCOSPO              Image Spot Custom Multi-Color Glass Gobo

Permacolor Dichroic Filters

1203-XXXX-SPOT              Image Spot Permacolor Dichroic Glass Filter, XXXX = the four digit color number




Product Numbers

296 00004 0401  - Image Spot LED Projector - IP40 - w/o Lens - Black

296 00004 0402  - Image Spot LED Projector - IP40 - w/o Lens - White

296 00004 0403  - Image Spot LED Projector - IP40 - w/o Lens - Silver


296 00004 0651  - Image Spot LED Projector - IP65 - w/o Lens - Black

296 00004 0652  - Image Spot LED Projector - IP65 - w/o Lens - White

296 00004 0653 - Image Spot LED Projector - IP65 - w/o Lens – Silver


296 00004 1651  - Image Spot LED Projector - IP65 w/DMX Cable - w/o Lens - Black

296 00004 1652  - Image Spot LED Projector - IP65 w/DMX Cable - w/o Lens - White

296 00004 1653  - Image Spot LED Projector - IP65 w/DMX Cable - w/o Lens - Silver
