The X-Effects LED and X-Effects LED HO RGBW Projectors are color-mixing fixtures that create dynamic lighting effects in wide range of indoor or outdoor applications. Effects are created by projecting colored light through the edges of two rotating pieces of Effects Glass that are mounted off-center of the optical path. This results in a projection with linear motion for creating reflected water, blowing fire, northern lights and other vivid, animated lighting effects.
Please note that the X-Effects LED Projectors do not ship with a lens. Choose from the available four lens accessories when ordering to achieve the beam spread your project requires.
The X-Effects LED Projectors feature either 1,400 or 3,000 (HO) lumens of output of 45 and 90 watts (HO) of power. The X-Effects LED HO can maintain over 100 lumens at 65ft+ (20m+).
The X-Effects LED Projectors are IP65-rated for indoor or outdoor use, offering the versatility to create dynamic lighting effects anywhere they are required.
Whether you need to shine your effect on a building across the street or on a wall five feet away, the X-Effects LED Projectors have the proper lenses to meet every projection need.
The X-Effects LED Projectors can achieve a variety of different lighting effects by changing gobos or adding color into either the Static Gobo/Filter position or into the two rotating Dynamic Effects Glass positions.
Lighting effects should be seen, not heard. The X-Effects LED Projectors are passively cooled enabling them to operate without noisy fans.
The X-Effects LED Projectors feature on-board controls of the fixture’s output, as well as the speed and direction of both Effects Glass Gobos. The fixtures can also be controlled via DMX and are RDM compatible.
Please complete this form
Specifications:
Machined aluminum alloy lens holder
Precision optics
Available beam angles: 19°, 30°, 50°, 70°
Available colors: Black, Silver
For outdoor installations where the lens is mounted facing upwards, we recommend purchasing the X-Effects LED Lens Cover #297000000020. This accessory helps prevent pooling of water in the lens, which can lead to projection distortion and accelerate lens wear.
Product Numbers:
The X-Effects LED Lens Cover accessory helps prevent pooling of water in the lens for outdoor installations where an X-Effects LED lens is mounted facing upwards.
Download the X-Effects® LED Lens Cover Installation Instructions:
Download the X-Effects® LED Lens Cover Installation Instructions
Product Numbers:
This X-Effects LED Framing Shutters provide control of the fixture’s beam-size and shape. The four-leaf shutter accessory can be installed in a variety of ways along the magnetic ring around the static gobo position, allowing the fixture’s beam to be cut from the top, bottom and/or both sides.
Specifications:
Number of Leaves: Four (top/bottom/left/right)
Product Numbers:
Rosco’s 4-Pattern Gobo Wheel gobos can create unique lighting effects when inserted into an X-Effects LED Projector. Four gobo patterns are combined onto a single Dynamic-sized Black & White glass gobo to provide four different designs to rotate through, without having to remove or replace any gobos.
The 4-Pattern Gobo Wheel gobos are sized and configured specifically for the second Gobo Rotation Carrier further from the LED. This Dynamic gobo slot provides the sharpest focus for the patterns. Simply line up the desired pattern into the optical path and stop the gobo rotation to have the preferred gobo displayed.
Replacement Effects Glass Gobo for the X-Effects LED Projector.
Note – the fixture ships with two of these gobos. This single-gobo accessory is available to replace gobos that may break or become lost during use.
Product Numbers:
Rosco’s textured-dichroic ColorWaves gobos can create unique, color-blended lighting effects when inserted into an X-Effects LED Projector. These gobos are available in two sizes to fit into the Static Color/Gobo Slot or the larger (96mm) gobos to fit into the fixture’s two rotating Dynamic Effects Glass positions.
Product Number:
XXXXXX = five digit gobo number
Visit the ColorWaves page to see all of the available options: www.rosco.com/colorwaves
Rosco’s clear, textured Image Glass gobos can create unique lighting effects when inserted into an X-Effects LED Projector. These gobos are available in two sizes to fit into the Static Color/Gobo Slot or the larger (96mm) gobos to fit into the fixture’s two rotating Dynamic Effects Glass positions.
Product Number:
XXXXXX = five digit gobo number
Visit the Image Glass page to see all of the available options: www.rosco.com/imageglass
A specialized, cyan-colored, dichroic glass filter that features wavy etches to allow a portion of the X-Effects LED Projector’s natural light through – helping to create a more-nuanced, realistic water effect.
Product Number:
A specialized, amber-colored, dichroic glass filter that features wavy etches to allow a portion of the X-Effects LED Projector’s natural light through – helping to create a more-nuanced, realistic fire effect.
Product Number:
A specialized, light green-colored, dichroic glass filter that features wavy etches to allow a portion of the X-Effects LED Projector’s natural light through – helping to create a more-nuanced, realistic Aurora Borealis/Northern Lights effect.
Product Number:
The Rosco Pole Mount is a rugged mounting accessory for attaching Rosco Projectors and Rosco Cube products to interior or exterior round poles.
Powder-Coated Steel support that provides rigid attachment and a clean, mounted installation.
1-3/5” (42mm) open tubing provides room for power/data cables for a clean installation.
Pole Mounts attach to any round structure via Stainless Steel Straps (kit sold separately).
Product Numbers:
The Rosco Wall Mount allows for mounting Rosco Projectors and Rosco Cubes to interior or exterior vertical surfaces.
Powder-Coated Steel support that provides rigid attachment and a clean, mounted installation.
1-3/5” (42mm) open tubing provides room for power/data cables for a clean installation.
Product Numbers:
The Rosco Surface Mount allows for mounting Rosco Projectors and Rosco Cubes to interior or exterior horizontal surfaces.
Powder-Coated Steel support that provides rigid attachment and a clean, mounted installation.
1-3/5” (42mm) open tubing provides room for power/data cables for a clean installation.
Product Numbers:
3’ (1m) safety cable with convenient threaded connector designed to wrap around the fixture’s mounting point to provide security for any Image Spot installation.
